Product Description
- Revenue generation for Tyre Service Providers
- Both N2 fill and Air to N2 conversion service for up to 4 tyres
- Cost effective to use
- Simple to set up
- Low life time costs - with high grade filtration and high performance components
- Guaranteed accuracy and robustness with ceramic pressure sensor
Key Product Features
- Rugged and reliable design
- Mobile to allow efficient and flexible positioning and usage
- N2 purity check point
- Can be fitted to meet EC standards
- Easy to operate and quick installation
- Strong support
- Tank contents gauge
- Electronic preset tyre inflation
- Auto-start inflation
- Digital display
- Up to 4 tyres at once
- Automatic flat tyre detection
1 purge inflation cycle from flat
2 purge inflation cycle, as standard - Software programme for conversions of up to 4 tyres from air to nitrogen
- Bespoke software for optimal nitrogen inflation with purge cycle
- Ceramic sensor - accuracy up to ± 0.5% of full scale reading
Specifications
Accuracy: To +/- 0.5% of full scale reading
Reading Accuracy: 0.1bar / 1psi / 5kPa
Max Inlet Pressure: 10bar / 145psi / 999kPa
Max Inflation Pressure: 5.5bar
N2 flow: 60l/min @ 8bar supply
Approvals
Exceeds EC Directive 86/217
Product Options
Part No. | Description | Hose Length | Tyre Valve Connection | Calibration |
---|---|---|---|---|
N2IA01/2 | Nitrogen Inflator with EC approved tank | 1 x 7.6m | Single clip-on | 0-145lbf/in² |
N2IA02/2 | Nitrogen Inflator with EC approved tank | 4 x 7.6m | Single clip-on | 0-145lbf/in² |
N2IC01/2 | Nitrogen Inflator with EC approved tank | 1 x 7.6m | Single clip-on | 0-10bar |
N2IC02/2 | Nitrogen Inflator with EC approved tank | 4 x 7.6m | Single clip-on | 0-10bar |
