Product Description
Other details:
• Inverter: IGBT (Semikron Make) Control PWM Technology
• With Pure Sine Wave Output
• Rectifier: Full wave Rectifier by Using IGBT Charger Power
• Factor Correction
• Filter: DC Power capacitors with choke Input Filter Specification:
• Rectifier: Bridge rectifier full wave
• Charger: IGBT Power Factor Charger
• Input PF: >.97g
• Charging Current: Depending upon the system
• Charging Voltage: Depending upon the system
• Ripple without battery: < 1%
• Regulation: +/-1%
• Frequency: 50Hz +/- 0.1Hz
• Waveform: True Sine wave
• Total Harmonic Distortion: Overload Capacity: 125% for 10Mins, 150%for 1Sec
• Inverter Type: IGBT Based PWM with Instantaneous Sine wave Control
• Duty Cycle: Continuous
• Manual Bypass: Provided
• Inverter Efficiency: >93%
• Converter Efficiency: >94%
• Converter Protection: MCB and HRC Fuses, soft start for 0-6o seconds from input power
• Inverter Production: MCB and HRC Fuses. High speed pulse by pulse electronic over voltage / under voltage production, over current trip with reset
• LCD display: Output Voltage, DC Voltage, Load in Watts, Battery Low Output Low/High, Overload
• Note:
• Image shown are just indicative and will change due to research and development activities
