Nitrogen Evaporator by Athena Technology

Nitrogen Evaporator:
AT-EV-50 Nitrogen Concentrator /Sample Evaporator (Turbo Athena Technology, Nitrogen Concentrator Model: AT-EV-50 is a Precision Sample Concentrator by Nitrogen Purging. It is a newly designed Sample Concentrator for multiple sample pre-concentration of in organic media. A Table Top Model. The unit can be set to a constant Flow and constant Temperature to ensure good evaporation. Also, the Nozzle height can be electrically set to the required level. It is fully microprocessor controlled and water bath, Temperature, gas station, more advantage LCD display, over Temp. Heater ON/OFF LED, door open display, high-temperature Thermal Coutour for safety for best quality and best performs.

Product Specifications:

• Vortex Shearing Concentration
• ASE (Dionex) Compatible upgrade Kit (For I-Chem vial 40mL, 60mL)

Time Range:
15 sec to 10 hours Time Set-up / down arrow keys (15 sec increments)
Temperature range: Ambient to 99°C (thermal cutout for safety)Temperature set-up / down arrow keys (1°C increment)
Start/stop: Green LED indication when process is On Display: LCD Digital Display Gas stations: 5 Nos. with LED indication
Gas regulator range: 0 to 100 PSI (approximate)Pressure gauge range: 0 to 100 PSI Controlled: Fully Microprocessor based Sample capacity: 50 Nos.Gas Line: 5 Nos.
Water tank capacity: 6.5 Ltr. (Not over flow)Dimensions: 30cm(H) x 40cm(W) x 55cm(L)Weight:20 Kgs (empty tank)
Colour: Athena Blue Exhaust: No fume hood required Power supply: 230 V AC / 3Amp
Error indication: LED indication with Buzzer

Technical Specifications:

• Space requirements: Tabletop or fume hood with minimum dimension L, W & H (cms) 70 x 50 x 65 table weight capacity 35 kg minimum requirement Work area: Flat, level, stable, surface Power supply: 230 AC/5amp single phase stable & well grounded Gas supply: Laboratory grade nitrogen Inlet pressure: 60 PSI minimum, 100 PSI maximum (And ON/OFF control valve)Exhaust: Exhaust duct outlet or fume hood - the exhaust duct must go outside the lab.Water bath capacity: 6.5 Ltr. distilled water (6.5 Ltr. do not overflow)

Rack Type Working volumes:

• 12mm x 75mm 04 ml
• 12mm x 100mm 05 ml
• 16mm x 100mm (Standard) 13 ml
• 15mm x 125mm 11 ml
• 15mm x 150mm 12 ml
• 17mm x 125 mm 15 ml
• 17mm x 150 mm 16 ml
• 18mm x 150mm 20 ml
• 20mm x 150mm 30 ml

• Precise manufacturing using latest technology -WaterJet Cutting & CNC fabrication
• High-Quality Pressure Gauge from Wika.
• Side Handles for easy movement
• SS 316 tank & Nozzle Manifold for durability and maintenance free
• Best Quality powder coating for great looks & to avoid rusting
• Silicon Heater with SS316 Water bath Tank system
• Specially Designed for fast & uniform heating
• Tank & Body gap is well insulated with imported Glasswool Sheet to avoid heat loss.
• Digital LCD Display
• Auto Cut off with precision sensor for Time, temperature & gas flow
• 5 Nitrogen Control valves with ON/OFF Switches
• 50 nitrogen –dispending nozzle in five horizontal rows
