Product Description
PV array of 1200Wp capacity
38,400 Liters per day from 30 meters head
Shut-off total dynamic head - 45 meters
Features
- IEC certified modules with 25 years warranty
- Advance System Safety Protection features like dry run, reverse polarity, low voltage and lightening arrestor
- Longevity Corrosion resistant galvanized iron mounting structures for longer life, withstand wind speed of 150 kmph
Benefits
- Grid change over option available to operate with grid power
- Auto ON/OFF feature for utilizing maximum solar energy
- Payback period (as compared to equivalent water from diesel pump) of 2 to 3 years
- Ideal for areas with low or minimum grid power
- 25 years warranty for the modules and 5 years warranty on pump and controller
Components
- Solar Module: 1200Wp
- Pump Capacity: 1HP
- Galvanized iron module mounting structure
- Variable Frequency Drive
- Suitable accessories pipe, cable, rope, etc.
Specifications
Solar Module: 1200Wp | Dynamic Pump Head: 30 m | Water Discharge: 38,400 LPD @ 30 m |
Product Specification
Specification | Value |
---|---|
Brand | Tata Solar |
Pressure | Low Pressure, Medium Pressure |
Motor Type | AC, DC |
Power Source | Electric, Solar |
Pump Type | Centrifugal Pump |
Pump Head | 15 mtr to 45 mtr |
Warranty | 24 months |
Condition | New |
Application | Agriculture, Submersible |
Solar module | Amrut |
Discharge outlet | 32 mm or 38 mm |
Discharge in LPM | 160 LPM to 70 LPM |
Maximum AMP | 1.8 A |
Size of Cable | Customized |
Power | 1000W |
Model | V 4/Radial flow/oil FILLED/SS Jacket |
Stage | 5 to 10 stage |
Voltage | 250 V-415 V |
Max OD of pump set | 95 mm |
Minimum Order Quantity | 1 Set |
